Gira Eco for KNX
Specification
Item no.
Room
Quantity
EAN
PU
PS
2045 00
4010337128069
1
Price system (PS) not equal to 1, 14 = reduced discount.
Note: For legal reasons, some products are not available in certain countries.
EAN 4010337128069
Item no. 2045 00PU 1
PS
Price system (PS) not equal to 1, 14 = reduced discount.
Note: For legal reasons, some products are not available in certain countries.
Features
- Integration of five charging points per device in the KNX system (can be fully configured via the ETS).
- Integration of five inverters per device in the KNX system (can be fully configured via the ETS). One of the inverters, as a hybrid inverter, can integrate a battery storage unit.
- Dynamic load management (DLM).
- Static load management (SLM).
- Mixed operation by different manufacturers.
- Phase switching (1- or 3-phase charging).
- Load imbalance management.
- Various charging options: Immediate; Eco (PV excess charging).
- Boost function (fast charging).
- Prioritisation of a charging point.
- Support for external electricity meter (ISKRA, PHOENIX CONTACT, generic) at charging points which do not have an internal electricity meter
- Grid-serving control.
Charging points
- Charging: Charging point status (status), Connected (status), Charging (status), Charge completed (status), Interrupt (set/status), Start/Stop (set/status), Unlock (set).
- Charging current: Set (status/set), Actual L1-L3, Actual (status).
- Power status values: Actual L1-L3, Actual (status).
- Energy status values: Actual L1-L3, Actual (status).
- Energy consumption status values: Last charge (status), Total (status).
- Fault status values: Fault, Last fault.
- Status values: Communication ID (EVCCID) (status), Internal charging point temperature (status), Temperature warning, RFID tag (status), Serial number, Charging point firmware version.
Inverter
- Display yield value (energy, power).
- Status values: Device status, fault, last fault, firmware version, serial number.
Hybrid inverter
- Display energy and power values. (Charging/discharging).
- State of charge (SoC).
- Status and fault.
Technical data
| Rated voltage | DC 24 V to 30 V |
| Power consumption | 2.3 W(DC 24 V external supply) |
| Ambient temperature | 0 °C to +45 °C |
| KNX communication | KNX/TP, S mode |
| KNX medium | TP1-256 |
| IP communication | Ethernet 10/100 BaseT |
| Connections | 2 x RJ45 (integrated switch), connection and junction terminals for KNX and 24 V |
Notes
- KNX Secure.
- Can be enhanced via firmware updates.
Dimensions
| Modular widths (MW) | 2 |
