DCS repeater
excl. VAT:
Recommended retail price, prices valid for United Kingdom as of the stated date 01/25
Price system (PS) not equal to 1, 14 = reduced discount.
Recommended retail price, prices valid for United Kingdom as of the stated date 01/25
Price system (PS) not equal to 1, 14 = reduced discount.
Necessary accessories
One of the following items:
Systemgerät Türkommunikation
Features
- Active component for upgrading a Gira door communication system with an audio and video function.
- Range extension and increase of the number of devices when using additional control devices.
- Amplification of the audio and data signals for the door communication system in both directions.
Repeater mode
- Interconnects two line segments, to double both the number of devices in a video or audio door communication system and the cable range.
- Important: An additional control device is required to supply the second line segment.
Multi-conversation mode
- In multi-conversation mode, the complete system is subdivided into several lines (one main line, up to five ancillary lines) interconnected via the DCS repeater.
- Power is supplied to each line by its own control device.
- Up to five DCS repeaters can be used in one system in multi-conversation mode.
Technical data
| Power supply | via the 2-wire bus |
| Connections | |
| 2-wire bus IN | 2 x plug terminal |
| 2-wire bus OUT | 2 x plug terminal |
| Memory card | microSD card (SDHC) up to max. 32 GB |
| Ambient temperature | -5 °C to +45 °C |
Notes
- Data backupThe configuration of the DCS repeater can be backed up to amicroSD card.
- Start-upStart-up of the DCS repeater is also possible withouta microSD card.
Scope of delivery
- The microSD card isnotincluded with delivery.
Dimensions
| Modular widths (MW) | 2 |
More links
Gira door communication configurator
The Gira door communication system enables systems of different types and sizes: from detached houses and apartment blocks to entire residential complexes. From simple audio and video systems to integration into a computer network. The Gira door communication configurator is a user-friendly online tool that makes the individual configuration of such systems a pleasure for house owners and administrators, but also for tradesmen and other professionals.
More
Guides/System basics
Basics, planning examples Door communication system Order no. 1736 90
