Flush-mounted DCS switching actuator
excl. VAT:
Recommended retail price, prices valid for United Kingdom as of the stated date 01/25
Price system (PS) not equal to 1, 14 = reduced discount.
Recommended retail price, prices valid for United Kingdom as of the stated date 01/25
Price system (PS) not equal to 1, 14 = reduced discount.
Necessary accessories
One of the following items:
Systemgerät Türkommunikation
Features
- Flush-mounted switching actuator for controlling an external gong or other device using the Gira door communication bus.
- Actuation of a zero-voltage switching contact (24 V SELV/ 50 µA to 1.6 A AC/DC) via the 2-wire bus.
- The flush-mounted switching actuator can be actuated by:the "Door" and "Light" buttons on the home station,the floor-call button on the home station,the call button on the door station, the call button on the home station,a zero-voltage button (in combination with the DCS button interface, 2-gang).
- The flush-mounted switching actuator can be used in four different operating modes: switching, timer/sec., timer/min., and pulse.
- Impulse function for controlling existing automatic staircase mechanisms.
- Switching time can be adjusted progressively from 1 to 10 s or 1 to 10 min., depending on the function set.
- LED display for programming, function selection, and time setting.
Technical data
| Power supply | via the 2-wire bus |
| Zero-voltage relay contact | 50 µA to 1.6 A at AC/DC 24 V SELV |
| Number of call buttons that can be taught in | max. 16 |
| Ambient temperature | -5 °C to +50 °C |
| Dimensions | |
| Flush-mounted switching actuator | W 43 x H 28 x D 15 mm |
Notes
- The flush-mounted switching actuator is intended for installation in a deep device box (60 mm deep) behind a DSC bus coupler.
Dimensions
| Width | 28.00 mm |
| Height | 43.00 mm |
| Depth | 15.00 mm |
More links
Gira door communication configurator
The Gira door communication system enables systems of different types and sizes: from detached houses and apartment blocks to entire residential complexes. From simple audio and video systems to integration into a computer network. The Gira door communication configurator is a user-friendly online tool that makes the individual configuration of such systems a pleasure for house owners and administrators, but also for tradesmen and other professionals.
More
Operating instructions
