Video distributor
Price system (PS) not equal to 1, 14 = reduced discount.
Note: For legal reasons, some products are not available in certain countries.
Price system (PS) not equal to 1, 14 = reduced discount.
Note: For legal reasons, some products are not available in certain countries.
Necessary accessories
Systemgerät Türkommunikation
Features
- The video distributor is an active component for line adjustment of the video signal.
- The video distributor distributes the video signal of the door stations, DCS-camera gateways and DCS-IP gateways to the home stations.
- The video distributor is required when the cable routing to the video components of the Gira door communication system is implemented as a branch line.
- The video distributor ensures the proper terminating resistance to prevent possible reflections of the individual branches and the resulting picture disturbances.
The combination housing makes three mounting types possible
- Surface-mounted (in a standard junction box).
- Flush-mounted (in a device box).
- As a DRA device (using the DRA adapter enclosed).
Technical data
| Power supply | DC 26 V ± 2 V (by 2-wire bus) |
| Connections | |
| 2-wire bus IN | 2 x screw terminal |
| 2-wire bus OUT | 6 x screw terminal |
| Ambient temperature | -25 °C to +70 °C |
| Dimensions | |
| Video distributor | W 36 x H 52 x D 27 mm |
Notes
- The video distributor is cascadable. A total of up to 15 video distributors and video multiplexers can be used in one system.
- No further configuration is necessary during commissioning because the video distributor automatically adapts to the existing mains supply.
Scope of delivery
- A DRA adapter is included.
Dimensions
| Width | 36.00 mm |
| Height | 52.00 mm |
| Depth | 27.00 mm |
